Aquapump Small pumping station

The economical solution for private households

Aquapump Small Mono system pumping station for faecal wastewater

When it comes to the disposal of wastewater outdoors, the Aquapump Small pumping station is the economical solution for detached and semi-detached houses. It offers modern “made in Germany” technology in a compact tank at an unbeatable price.

The Aquapump Small pumping station is available either as a Mono or Duo system with or without a control unit. An optional upper section makes it particularly flexible for underground installation

Advantages  Product overview

Aquapump Small Duo system pumping station for faecal wastewater
Installation diagram for Aquapump Small pumping station for faecal wastewater
Aquapump Small Mono system pumping station for faecal-free wastewater
Aquapump Small Duo system pumping station for faecal-free wastewater
Installation diagram for Aquapump Small pumping station for faecal-free wastewater
Pumping performance diagram for pumps GTF 600 and GTF 1250
Warranty for KESSEL polyethylene tanks

100% waterproof and odour-tight

Like all KESSEL chambers, the tank of the Aquapump Small pumping station is also absolutely waterproof and odour-tight. This is what we stand for with our guarantee that we have voluntarily extended to 20 years.

Isolated pump for Aquapump Small pumping station

Suspended pump bearings

The version for faecal-free wastewater has either one or two GTF 600 or GTF 1250 type suspended pumps. The sound decoupling of the tank reduces the noise level during operation. The non-clogging multi-vane vortex impeller with a 30 mm free ball passage provides for added safety.

The version for faecal wastewater works with either one or two STF 1300 type suspended pumps. The diameter of the ball passage is 40 mm.

Drilling surfaces for Aquapump Small pumping station

Pre-scored drilling surfaces

Additional connections for the ventilation pipe, inlet and outlet pipe can be made at the pre-scored drilling surfaces on the side.

Aquapump Small pumping station

Tool-free maintenance

The pump(s) is/are particularly easy to remove and maintain thanks to quick-release closures.

Pumping station Aquapump Small

Type of wastewater: wastewater without sewage

PumpLevel measurement instrumentNumber of pumpsAlarm sensor Item no.
828811 GTF 600 - 2 Float switch 828811
Show
828851 GTF 1250 - 2 Float switch 828851
Show
829810 GTF 600 - 1 -829810
Show
829811 GTF 600 - 1 Float switch 829811
Show
829850 GTF 1250 - 1 -829850
Show
829851 GTF 1250 - 1 Float switch 829851
Show

Type of wastewater: wastewater with sewage

PumpLevel measurement instrumentNumber of pumpsAlarm sensor Item no.
828711 STF 1300 Float switch 2 Float switch 828711
Show
829710 STF 1300 Float switch 2 -829710
Show
829711 STF 1300 - 2 Float switch 829711
Show
Individual solutions, plant construction employees

Not found the right product?

In addition to our standard pumping stations, we develop individual solutions for special requirements – in terms of form, function and dimensioning – at the customer's request.
